High Capacity 260W/K 380W Fan Heat Exchanger

High Capacity 260W/K 380W Fan Heat Exchanger

Product Details:

Place of Origin: Shenzhen, China (Mainland)
Brand Name: ESTEL
Certification: ISO9001, CE, 3C, FCC, TLC
Model Number: ET260EE

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: carton + foam + wooden case
Delivery Time: 7-10 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 16,000 sets per month
Get Best Price Contact Now

Detail Information

Input Voltage: -48VDC Cooling Capacity L35/L35: 260W/K
Power Consumption L35/L35: 380W IP Grade: IP55
Dimensions (Include Flange): H×W×D: 1340*660*240mm Airflow: 1500m3/h
High Light:

380W Fan Heat Exchanger

,

260W/K Fan Heat Exchanger

,

260W/K cabinet heat exchanger

Product Description







High Capacity 260W/K Enclosure Heat Exchanger Remote Communication Low Noise LED Display Outdoor Cabinet HEX







Functional Characteristics



* Remote measuring, remote communication, remote control, which can realize multiple

automatic protection and comprehensive self-testing function;

* Power supply voltage range;

* LED display, all the settings can changed at the field;

* Strict process control and international brand parts deployed to ensure high quality and

product;

* Dry contact alarm output, NO/NC optional;

* Anti-theft design, without the protection cover.





Application



ESTEL is provide temperature solutions for communi-cations, with the world’s advanced technology and rapid development, Meet the increasingly stringent reli-ability requirements. Create a cool, dry and safe envi-ronment for the operation of equipment and electrical; The product is widely used in outdoor communication cabinets, electrical cabinets, industrial cabinets and other occasions need heat dissipation.





Technical Data



Dimensions (Include flange): 1340*660*240 mm

Dimensions(Without flange) : 1300*620*240 mm

Weight: 60 kg

Mounting method: Embedded

Application temperature :-40-70 ℃

Working temperature: -40-65 ℃

Input voltage: -48VDC

Cooling capacity: 260 W/K

Power consumption: 380 W

Airflow: 1500 m3/h

IP grade: IP 55

Noise: 65 dB (A)

Surface treatment : Powder coating RAL7035





Performance Curve



High Capacity 260W/K 380W Fan Heat Exchanger 0





Drawing



High Capacity 260W/K 380W Fan Heat Exchanger 1





Product Picture

                                      High Capacity 260W/K 380W Fan Heat Exchanger 2





Actual Case





High Capacity 260W/K 380W Fan Heat Exchanger 3
