19" Rack IP55 Waterproof ESTEL Outdoor Battery Enclosure

19" Rack IP55 Waterproof ESTEL Outdoor Battery Enclosure

Product Details:

Place of Origin: China
Brand Name: ESTEL
Certification: ISO9001, CE, RoHs
Model Number: ET6565140-BA-2D

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Wooden case with pallet
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 1000 sets per month
Get Best Price Contact Now

Detail Information

Dimention: H×W×D 1400×650×650mm Installation Rack: 19 Inch Rack And Tray
Material: Galvanized Steel, Double Wall With Heat Insulation Door: 1 Front Doors And 1 Rear Doors
Cooling System: AC220V 500W Air Conditioner Coating: Outdoor Anti-corrosion Powder Coating
High Light:

ESTEL Outdoor Battery Enclosure

,

IP55 waterproof Outdoor Battery Enclosure

,

IP55 outdoor electronics cabinet

Product Description

19" Rack IP55 Waterproof ESTEL Outdoor Battery Enclosure



Front Back Access Insulated Outdoor Battery Cabinet IP55 19" Rack Mount Battery Enclosure With Air Conditoner Cooling





Overview



ESTEL is a high-tech enterprise integrating R & D, production and sales. The total area of the factory is 3000 square meters, the total number of employees is about 150, and the annual output sales are nearly 100 million RMB. Since its establishment, the company has been focusing on outdoor integrated cabinet, cabinet air conditioning, heat exchanger, embedded switching power supply, environment monitoring system, power distribution research and development, production and sales.





Configuration List





No. Item Quantity Unit Specs
1 Outdoor Telecom Cabinet 1 Set

(1) External Dimension: H×W×D 1400×650×650mm

(2) One compartment: battery compartment, including 19” rail and tray

(3) With one front door and one back door,totally 2 doors, and anti-theft three point lock for outdoor cabinet (support padlock)

(4) Material: galvanized steel; double wall with heat insulation

(5) IP Grade: IP55

2 Air Conditioner 1 Set Cooling capacity: 500W, AC220V, 50HZ;
3 Fans 1 PC DC48V
4 Door Sensor Switch 2 PC Used for controlling LED lamp on/off
5 LED Lamp 2 PC 48V LED lamps
6 Package 1 Set Wooden case




Environment conditions



1 Temperature Working Temperature: -40°C ~ +55°C
Storage Temperature: -50°C ~ + 70°C
Transport Temperature: -50°C ~ +70°C
2 Relative Humidity 5% ~ 100%
3 Air Pressure 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
4 Solar Radiation Intensity 1124 × (1±5%)W/m2





Cabinet Picture

19" Rack IP55 Waterproof ESTEL Outdoor Battery Enclosure 0



Packing-wooden case



19" Rack IP55 Waterproof ESTEL Outdoor Battery Enclosure 1



Other Similar Cabinet



19" Rack IP55 Waterproof ESTEL Outdoor Battery Enclosure 2
