• Telecommunication Outdoor Telecom Enclosure with Galvanizing Surface Treatment
  • Telecommunication Outdoor Telecom Enclosure with Galvanizing Surface Treatment
  • Telecommunication Outdoor Telecom Enclosure with Galvanizing Surface Treatment
Telecommunication Outdoor Telecom Enclosure with Galvanizing Surface Treatment

Telecommunication Outdoor Telecom Enclosure with Galvanizing Surface Treatment

Product Details:

Place of Origin: Shenzhen, China (Mainland)
Brand Name: ESTEL
Certification: ISO9001, CE, 3C, FCC, TLC, IP55
Model Number: ET-150100200-1

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Wooden case
Delivery Time: 15-20 working days
Payment Terms: L/C, D/A, D/P, T/T, MoneyGram
Supply Ability: 5,000 sets per month
Get Best Price Contact Now

Detail Information

Environment Monitoring Unit: 2U Anti-corrosion: YES
Surface Treatment: Galvanizing Custom Made: Support
Fans: DC48V LED Lamp: 2 PCS
High Light:

DC48V Outdoor Telecom Enclosure


2U Outdoor Telecom Enclosure


DC48V telecommunication enclosure

Product Description

Telecommunication 2U Outdoor Telecom Enclosure Galvanizing Surface Treatment


1. Description Of Outdoor Telecom Enclosure

Outdoor cabinets are designed to provide a safe solution to install telecommunications equipment in outdoor conditions. These cabinets are offering protection against different weather conditions, dust and vandalism. The cabinet is with one compartment. The cabinet is equipped with a power system, lightning protection and grounding system, temperature control system, lighting system, and user equipment installation space.


2. Feature Of Outdoor Telecom Enclosure

>>> Improved thermal design, efficient energy saving, effectively extending the battery life

>>> Support for fast assembly, ready for the summit, multi-scene roof installation

>>> Dynamic environment monitoring system, full alarm signal detection, real-time alarm information reported

>>> Anti-corrosion

>>> Surface treatment: Degreasing, Derusting, rustproof Phosphating (or galvanizing),

powder coated.

>>> Hidden hinge, inside screws, enhance the theft-proof

>>> Support Custom Made


3. Enclosure And Accessories List

No. Item Quantity Unit Remark
1 Outdoor Telecom Cabinet 1000*1500*2000mm (D*W*H) 1 set
2 Fans DC48V 4 set
3 Temperature Switch 2 pcs
4 Sensors (including 1 smoke sensor, 2 door alarm, 2 LED lamp, 1 water sensor, and 1 temperature and humidity sensor.) 1 set 2U environment monitoring unit is optional
5 PDU (grade B lightening arrestor, 63A/2P*1, 63A/1P*2, 32A/1P*2, 16A/1P*4, repair socket *1) 1 Set
6 Packing: carton+ pallet 1 Set


4. Technical Parameters

Item Technical Parameter
Temperature Working temperature range: -40℃~ +60℃
Sorage temperature range: -50℃~ +70℃
Transport temperature range: -50℃~ +70℃
Relative Humidity 5%-- 100%
Air Pressure 62kpa~ 101kpa (similar to altitude 0m ~ 5000m)
Radiation Intensity 1400* (1±5%) W/m2
Protection Grade IP45


5. Enclosure Cooling

2 DC48V fans for each compartment, totally 4 fans.


6. Application Of Outdoor Telecom Enclosure

The intelligent temperature measuring machine can be installed in the main entrances of crowded places such as enterprises,schools, hotels, shopping malls, office buildings, banks, government halls, etc., to monitor the temperature of employees, customers, and visitors in real time, effectively helping to prevent epidemics.


7. Cabinet Structure

(1) Cabinet External Dimension: 1000*1500*2000mm(D*W*H);

Height of cabinet base: 200mm;

Height of top cover: 150mm

Material: cold rolled steel, outdoor power coat


8. Drawing and Pictures

Telecommunication Outdoor Telecom Enclosure with Galvanizing Surface Treatment 0


9. Grounding

The cabinet include grounding copper bar, 4mm thick, with 10×M6 flare-in nuts, 2×M8 flare-in nuts, 2×M10 flare-in nuts. The grounding bar is nickel plated. The screw is made from copper bar and with passivation surface treatment.


10. Door Alarm

>>>Technical Parameters:

Contact power: ≤10W

Voltage: ≤28VDC

Current: ≤0.5A

Contact impedance: ≤300mΩ

Action distance: 35mm

Fixing mode: embedded

Safety standard(UL):94-HB


When forcible entry (forcible opening the cabinet door) happens, the door sensor will send the door alarm signal, and transmit the alarm signal to the monitoring center in switching mode.


11. Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Payment Terms: T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability: 8,000 sets per month
Delivery Time: 15-20 working days
Packaging Details: wooden case




Q1: Are you a manufacturer?
A: Yes, we are a experienced manufacturer with our own design and production lines.
Q2. Do you have any MOQ limit for outdoor cabinet ?
A: Low MOQ, 1pc for sample checking is available.
Q3: Can I get sample order?
A: Yes, we would like to get your sample order for testing our quality, the sample cost is paid by the customer.
Q4: Are you able to customize items with design or logo?
A: Yes, OEM & ODM is available.
Q5: How do you ship the goods and how long it will take?
A: We normally make shipment by sea or air which usually takes about 10- 50 days depend on the destination.
Q6: How long is the product warranty ?
A: We guarantee all our products 12 months warranty.
