IP55 Two Doors 20U Waterproof Network Cabinet 500W Air Conditioner
Product Details:
| Place of Origin: | China |
| Brand Name: | ESTEL |
| Certification: | ISO9001, CE, RoHs |
| Model Number: | ET6565130-419-2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case |
| Delivery Time: | 3-4 weeks |
| Payment Terms: | L/C, Western Union, T/T |
| Supply Ability: | 5000 pcs/month |
|
Detail Information |
|||
| External Size: | H*W*D 1300*650*650mm | Layout: | Installing 19” Equipment |
|---|---|---|---|
| Cooling: | Air Conditioner | Door: | With Two Doors |
| Lock: | Anti-theft Three Point Lock | Structure: | Single Wall, With Insulation |
| High Light: | 20U Waterproof Network Cabinet,IP55 Waterproof Network Cabinet,20U Outdoor Equipment Cabinet |
||
Product Description
IP55 Two Doors 20U Waterproof Network Cabinet 500W Air Conditioner
1. Outdoor Telecom Cabinet
Our telecom Cabinet can provide complete solutions for outdoor working environment and safety management of telecom base station. As a base station, it can integrate the main equipments, system power supply, AC and DC power distribution, environment monitoring, batteries, lightning protection and grounding devices. As functional cabinet (battery cabinet, power supply cabinet, transmission cabinet etc.), it can help telecom carriers to realize easy station obtaining, energy saving.
2. Outdoor Telecom Cabinet Features
- Cooling by air conditioner
- High integration, compact structure, easy installation and migration on later stage
- Anti-theft three point lock
- Full protection: door sensor, smoke sensor, water sensor, temperature & humidity sensor. Environmental monitoring system provides alarm.
- Material: galvanized steel or as customer's requirements
- High integration, small footprint, short construction period, reduce the construction cost
- Improved thermal design, efficient energy saving, effectively extending the battery life
- Support custom made
3. Technical Parameters
| Item | Type | Technical Parameter |
| Structure | Dimension | External Size H*W*D 1300*650*650mm |
| Layout | One compartment, used for installing 19” equipment | |
| Equipment Installation Method | 19” rack | |
| Door | With Two doors, and anti-theft three point lock for outdoor cabinet (support padlock) | |
| Material | Galvanized steel, single wall with thermal insulation | |
| Structure |
single wall, with insulation One front door and one rear door Anti-theft three-point lock device Door stopper / wind lock is installed on the inside of the cabinet door Door with good sealing, waterproof and dustproof Include standard 19“ rack inside the cabinet, high compatibility. Equipped with cable manager Cable inlets at the bottom of cabinet |
|
| Ingress Protection | IP55 | |
| Temperature Control | Cooling | Air conditioner |
| Lighting | LED lamp | 220VAC |
| Temperature | Temperature | Working Temperature: -40°C ~ +55°C |
| Storage Temperature: -50°C ~ + 70°C | ||
| Transport Temperature: -50°C ~ +70°C | ||
| Humidity | Relative Humidity | 5% ~ 100% |
| Pressure | Air Pressure | 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude) |
| Radiation Intensity | Solar Radiation Intensity | 1120 × (1±5%) W/m2 |
4. Accessories List
| No. | Item | Quantity | Unit | Specs |
| 1 | Outdoor Telecom Cabinet | 1 | Set |
(1) External Dimension H×W×D 1300× 650× 650mm. (2) One compartment: including 20U 19” rack. (3) With one front door, with three point lock for outdoor cabinet. (4) Material: galvanized steel, single wall with thermal insulation. (5) Floor installed. |
| 2 | Air Conditioner | 1 | Set |
Compressor type air conditioner Cooling Capacity: 500W Power Supply: 220VAC, 50Hz |
| 3 | Fan | 2 | Set | 220VAC |
| 4 | LED Lamp Switch | 1 | PC | For controlling LED lamp on/off |
| 5 | LED Lamp | 1 | PC | 220VAC |
| 6 |
Environment Monitoring System |
1 | Set |
1× environment monitoring unit,19”, 1U, 220VAC, SNMP communication 1× smoke sensor, 1× water sensor, 1× temperature & humidity sensor, 1× door sensor, |
| 7 | Package | 1 | Set | Wooden Case |
5. Environment Monitoring System
Environment monitoring unit,19”, 1U, 220VAC, SNMP communication
1× smoke sensor,
1× water sensor,
1× temperature & humidity sensor,
1× door sensor
6. Cabinet Application
· Environmental monitoring
· CCTV and security systems
· Base station
· Mobile & Radio, 3G 4G 5G, Tetra, Microwave
· Telecommunication
· Internet service providers
7. Cabinet
8. Delivery Time
Usually about 25-30 days. The exact lead time need to be confirmed according to the quantity of order.
9.Cooling System
220VAC air conditioner with 500W Cooling capacity, installed on the front door of the cabinet.
10.Packing and Shipment
FAQ
Q1: Are you a manufacturer?
A: Yes, we are a experienced manufacturer with our own design and production lines.
Q2. Do you have any MOQ limit for outdoor cabinet ?
A: Low MOQ, 1pc for sample checking is available.
Q3: Can I get sample order?
A: Yes, we would like to get your sample order for testing our quality, the sample cost is paid by the customer.
Q4: Are you able to customize items with design or logo?
A: Yes, OEM & ODM is available.
Q5: How do you ship the goods and how long it will take?
A: We normally make shipment by sea or air which usually takes about 10- 50 days depend on the destination.
Q6: How long is the product warranty ?
A: We guarantee all our products 12 months warranty.
